200mm Steel Wheel 5000/3750kg Capacity Castor (R865)

Wheel Diameter: 200mm

Castor Frame Type: Rigid

Wheel Width: 75mm

Wheel Type: Spheroidal Graphite (SG) Iron

Wheel Code: SG836

Wheel Bearing Type: Taper Roller Bearing

Castor Height: 320mm

Maximum Load Capacity: 5000kg

Recommended Load Capacity: 3750kg

The R865 manufactured by Richmond Rolling Solutions is a rigid frame castor and is fitted with a semi pneumatic wheel. This rigid castor is part of our 5000 series range and has a maximum capacity of 5000kg. The R865 is assembled with taper roller bearings on the castors axle. The rigid frame of this castor only allows linear movement unless used with swivel castors. The overall semi pneumatic wheel diameter is 200mm, the wheel width is 75mm and can be ordered separately (SG836).

View Specifications View Specifications Shipping Information

Specifications

Product Code	R865
Wheel Diameter (mm)	200
Frame Type	Rigid
Wheel Width (mm)	75
Wheel Type	Steel
Wheel Code	SG836
Wheel Bearing Type	Taper Roller Bearing
Castor Height (mm)	320
Maximum Load Capacity (kg)	5000
