| Product Code | R502NY |
|---|---|
| Wheel Diameter (mm) | 125 |
| Frame Type | Rigid |
| Wheel Width (mm) | 35 |
| Wheel Type | Nylon |
| Wheel Code | NY501 |
| Wheel Bearing Type | Stainless Steel Sleeve |
| Castor Height (mm) | 159 |
| Swivel Radius (mm) | 102 |
| Maximum Load Capacity (kg) | 330 |
| Recommended Load Capacity (kg) | 250 |
| Barcode / GTIN |
125mm Nylon Wheel 330Kg Capacity Castor (R502NY)
$122.15 ex. GST
$140.47 inc. GST
Available Online
Wheel Diameter: 125mm
Castor Frame Type: Rigid
Wheel Width: 35mm
Wheel Type: Nylon
Wheel Code: NY501
Wheel Bearing Type: Stainless Steel Sleeve
Castor Height: 159mm
Maximum Load Capacity: 330kg
Recommended Load Capacity: 250kg
Precision built for durability under extreme working conditions, the Heavy Duty Welded Series is ideal for the exhaustive demands of industrial environments when a low profile high load bearing castor is required. Featuring a precision machined swivel ball race provides an unrivalled ultra smooth swivel action and a king pin made of high tensile steel to withstand high side impact loads. Finished in an attractive zinc plating to provide corrosion resistance, Richmond can also supply the heavy duty welded series in stainless steel for sue in high corrosive environments.
The R502NY from Richmond Wheel and Castor Co. is a rigid frame castor and features a nylon wheel. This rigid castor is one of our heavy duty welded series range and can hold loads up to 330kg. The R502NY wheel is fitted with Stainless Steel Sleeve Bearings. The rigid frame design of this castor only allows linear movement unless used with swivel castors. The diameter of the nylon wheel is 125mm, the wheel width is 35mm and you can order separately (Part Number: NY501).
